VARITO VA-W543TG4 4MP IP Warmlight Dome Camera

VARITO VA-W543TG4 4MP IP Warmlight Dome Camera

VARITO VA-W543TG4 4MP IP Warmlight Dome Camera is an advanced surveillance solution designed for high-quality video monitoring in both indoor and outdoor environments. Equipped with 4MP resolution, smart infrared (IR) night vision and AI-powered detection features, this camera ensures accurate identification of people and vehicles even in low-light conditions.

Product Details:

Brand: VARITO
Model VA-W543TG4
Brand Origin Germany
Lens 2.8mm Fixed Lens
Sensor 1/2.9″ Cmos Sensor
IR Distance 20~25m



Many Features

0
1

Max resolution

4MP@20fps: 5MP HD board Lens

0
2

Camera Sensor

1/2.9″ 4MP low illumination CMOS Sensor

0
3

Camera Lens

2.8mm Fixed Lens

0
4

Camera Warmlight

4 Pcs Warmlight LEDs

Specification

Item Specification
General Specifications
Housing Half Metal Housing
Infrared LED 4pcs warm-light led
Warm light distance 25~30m
Chip-set T31N+S2G
Sensor 1/2.9″ 4MP low illumination CMOS Sensor
Image Storage & Deletion Save no less than 200,000 pictures and automatically delete expired pictures
Lens 2.8mm Fixed Lens
Day & Night Full Color
Led Control Warm light, auto off, support 0-100 brightness adjust
3D DNR & D-WDR Support all
Mirror Off/horizontal mirror/vertical mirror/180° flip
Night Vision Frame Rate Drop On/Off
Light collection strategy No light/Human figure light/License plate light
Exposure Control Strong light suppression/backlight compensation, shutter priority/gain priority
Image Setting Brightness, contrast, sharpness, saturation, hue
Power Supply DC12V /PoE (support)
PCB Board Size 38*38mm, Positioning hole size: 34*34mm IR-CUT pitch 20mm
Working Temperature -15°C ~ 50°C
Working Humidity 0%~90%
Video Type Composited stream/video stream
Audio Coding G.711u / G.711A 64Kbps, Support sound monitoring and one-way / two-way voice intercom
Audio Coding G.711u / G.711A 64Kbps, Support sound monitoring and one-way / two-way voice intercom
Common Events
Motion Detection Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Support full screen/area detection, Linkage settings support: light alarm\sound alarm
Masking Alarm Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Supports 1 detection area, Linkage settings support: light alarm\sound alarm
Area Intrusion Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Support video stream overlay detection frame, Supports 1 detection area & can draw a polygonal detection area (consisting of six points), Supports detection of specified target types: people, cars (electric vehicles can also be detected)
Line-Cross Detection Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Linkage settings support: light alarm\sound alarm, Supports 1 detection line, and the detection line supports A->B detection direction, The target detection type is people or cars (electric vehicles can also be detected)
Smart Events
Person Loitering Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Support setting the stay time (10, 3600) seconds, Support video stream overlay detection frame, Linkage settings support: light alarm\sound alarm, Supports 1 detection area & can draw a polygonal detection area (consisting of six points)
Absent Alarm Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Support setting the stay time (10, 3600) seconds, Support video stream overlay detection frame, Linkage settings support: light alarm\sound alarm, Supports 1 detection area & can draw a polygonal detection area (consisting of six points)
Vehicle illegal Parking Support all-day/nighttime arming mode, Supports custom configuration of deployment time by week, 4 time periods per day, Support setting the stay time (10, 3600) seconds, Support video stream overlay detection frame, Linkage settings support: light alarm\sound alarm, Supports 1 detection area & can draw a polygonal detection area (consisting of six points)
Smart Events
Main stream PAL: 2MP 25 frames/3MP 25 frames/4MP 25 frames
Sub stream PAL: D1 @25 frames/VGA @25 frames/Q720P @25frames/864*480@25 frames
Video Coding Smart 265, H.265, H.264 Standards
Video bit rate Fixed bit rate/variable bit rate
Video Type Composited stream/video stream
Audio Coding G.711u / G.711A 64Kbps, Support sound monitoring and one-way / two-way voice intercom
Smart Events
Network protocol TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP
Connection Protocol Onvif protocol
Streams 4 Concurrent Live View
Safe Mode Authorized username and password, HTTPS encryption, RTSP verification
Motion Detection Set detection area, can set multi-level sensitivity
Blockage alarm Supports 1 local
Blockage alarm Supports 1 local
Privacy Mask Alarm Support 1 area
Privacy Mask Support 4 area occlusion blocks
Event linkage Arming time supports all-day arming/night arming/custom arming
Device Abnormal Inspection Network disconnection, IP conflict, illegal access alarm
Network Port RJ45 10M/100M network self-adaptation
P2P Support
Smart Phone iPhone, iPad, Android, Android Pad
APP Support (Optional – APP: VMYCAM)
IMS lite VMYCAM /SeeEasy
Character Overlay (OSD) Support time OSD/title OSD, The main code stream font Supports 12-60pt & the sub-code rate font supports 12-24pt

Product Description

At the core of the VARITO VA-W543TG4 is a high-performance 4-megapixel image sensor that captures crisp, ultra-high-definition video. Unlike traditional security setups that rely on harsh invisible infrared arrays, this innovative model utilizes advanced Warmlight LEDs. When ambient light drops below a functional threshold, the soft, warm white light activates.

AI Series Full Color IP Camera

The VARITO VA-W543TG4 4MP IP Warmlight Dome Camera solves this critical vulnerability. Engineered with cutting-edge illumination technology, this premium dome camera transitions seamlessly from daylight clarity to full-color nighttime monitoring, ensuring your property is protected around the clock.
XR3G-140100C
XR3G-140100D

Smart IR night vision for outdoor surveillance

VARITO continues to lead the global security market by engineering hardware that bridges the gap between sophisticated aesthetics and rugged reliability. The VA-W543TG4 Warmlight Dome Camera exemplifies this standard, offering seamless system integration, intuitive remote viewing, and long-term operational stability. When you choose VARITO, you are investing in a legacy of precision engineering designed to protect your assets, optimize your operations, and provide absolute peace of mind.

We Provide Multiple Solutions

Delivering clear video and intelligent security monitoring
varito-XR3G-140100C
Warmlight
304 Stainless Steel
Warmlight
Area Intrusion
Barcode-QR
Area Intrusion
DNR & WDR
Barcode-QR
DNR & WDR
Light Hunter
Radiation-Shield
Light Hunter
IR Solutions
Scanning Tunnel
IR Solutions
IP Solutions
Display-Screen
IP Solutions
Human Detection
Control-Console
Human Detection

Interactive Images

Easy Installing, NO Need Any Special Electrician Skills Fix on ground, connect to power supply, it will work
Before Image
After Image

Product Details and Dimensions

All the details and dimensions can be customized according to your project site

varito XR3G-120100D
+
T31N+S2G Chip-set
+
Half Metal Housing
+
2.8mm Fixed Lens
+
Warm-light led
VARITO 4MP IP Warmlight Dome Camera

More Information

Smart Access Control Solution for Modern Security

Illuminating 24/7 Security: VARITO VA-W543TG4 4MP IP Warmlight Dome Camera

In the realm of modern surveillance, high-resolution imagery is only half the battle. True security requires the ability to capture vivid, actionable details even in pitch-black environments. Standard infrared cameras often fall short, delivering grainy, monochrome night vision that obscures crucial details like clothing colors or vehicle features. The VARITO VA-W543TG4 4MP IP Warmlight Dome Camera solves this critical vulnerability. Engineered with cutting-edge illumination technology, this premium dome camera transitions seamlessly from daylight clarity to full-color nighttime monitoring, ensuring your property is protected around the clock.

Crystal-Clear 4MP Resolution with Intelligent Warmlight Technology

At the core of the VARITO VA-W543TG4 is a high-performance 4-megapixel image sensor that captures crisp, ultra-high-definition video. Unlike traditional security setups that rely on harsh invisible infrared arrays, this innovative model utilizes advanced Warmlight LEDs. When ambient light drops below a functional threshold, the soft, warm white light activates. This gentle illumination serves two vital functions: it provides enough visible light for the camera to record rich, full-color video in total darkness, and it acts as an active visible deterrent to potential intruders. Whether you are expanding a corporate security network or updating an existing VARITO IP Surveillance Camera ecosystem, the VA-W543TG4 delivers unmatched visual fidelity when you need it most. HTML

Whether you are expanding a corporate security network or updating an existing VARITO IP Surveillance Camera ecosystem, the VA-W543TG4 delivers unmatched visual fidelity when you need it most.

Building a Unified VARITO Enterprise Security Framework

A standalone camera can flag an incident, but a comprehensive security posture requires an interconnected ecosystem. For businesses aiming to deploy intelligent automation, pairing this hardware with the VARITO AI Series Surveillance Camera lineup unlocks deep-learning analytics like line crossing, facial recognition, and perimeter protection. To handle the massive data streams generated by these high-definition 4MP feeds, routing your network into a dedicated, high-capacity VARITO NVR (Network Video Recorder) ensures secure, uninterrupted, and easily searchable video storage. HTML

For businesses aiming to deploy intelligent automation, pairing this hardware with the VARITO AI Series Surveillance Camera lineup unlocks deep-learning analytics like line crossing, facial recognition, and perimeter protection. To handle the massive data streams generated by these high-definition 4MP feeds, routing your network into a dedicated, high-capacity VARITO NVR (Network Video Recorder) ensures secure, uninterrupted, and easily searchable video storage.

For large-scale commercial facilities, industrial parks, and high-security zones, video monitoring is optimized when paired with physical access controls. Integrating your surveillance grid alongside a physical Car Parking Barrier System allows security personnel to visually verify license plates and driver identities in real time. Similarly, staging dome cameras at main pedestrian entrances equipped with an Archway Metal Detector or an X Ray Baggage Scanner creates an impenetrable screening checkpoint. HTML

Integrating your surveillance grid alongside a physical Car Parking Barrier System allows security personnel to visually verify license plates and driver identities in real time. Similarly, staging dome cameras at main pedestrian entrances equipped with an Archway Metal Detector or an X Ray Baggage Scanner creates an impenetrable screening checkpoint.

The VARITO Brand Authority Advantage

VARITO continues to lead the global security market by engineering hardware that bridges the gap between sophisticated aesthetics and rugged reliability. The VA-W543TG4 Warmlight Dome Camera exemplifies this standard, offering seamless system integration, intuitive remote viewing, and long-term operational stability. When you choose VARITO, you are investing in a legacy of precision engineering designed to protect your assets, optimize your operations, and provide absolute peace of mind.

Key Features & Benefits

1. Vivid Full-Color Night Vision: Eliminates black-and-white nighttime footage, rendering accurate colors for facial and clothing identification. 2. Weatherproof and Vandal-Resistant Dome: Housed in a rugged, compact dome casing designed to withstand harsh outdoor elements and physical tampering. 3. Advanced Bandwidth Efficiency: Utilizes smart H.265+ video compression to minimize storage consumption without sacrificing 4MP image quality. 4. Power over Ethernet (PoE): Simplifies installation by carrying both power and high-speed data over a single network cable. 5. Remote Monitoring: Access live footage anytime via mobile or PC 6. Smart IR Night Vision: Clear image even in complete darkness

Ideal Applications

  • Corporate Offices
  • Residential Buildings
  • Factories and Warehouses
  • Shopping Malls
  • Banks and Financial Institutions
  • Parking Areas and Outdoor Perimeters
Its intelligent features and high-resolution imaging make it a reliable choice for modern surveillance needs.
