Many Features
Multi-zone Technology:
33 zone detection, which identifies metal more accurately. Promise zone more accurately and quickly identify metal,
while tracking metal moving position sound and light alarm.
Large screen Technology:
7-inch LCD screen, new debugger interface, easy to understand.
Detection of objects:
Magnetic, non-magnetic and alloy metals can be detected.
Super-strong shell protection technology:
IP55 superior protection performance
Anti-electromagnetic interference:
It adopts DSP digital signal processing technology to automatically
scan and detect the mechanical and electromagnetic interference
Working frequency band:
up to 100 working frequency bands, multiple devices work side by side with the same 50cm without interfering with each other.
Detection area:
The basic structure of the human body is divided into 6-18 detection
areas, so that the sensitivity distribution of the detection area is not
only blind and more uniform.
Detection zone sensitivity:
The sensitivity of a single zone can be up to 0-999. Built-in high and
low sensitivity programs for quick and easy adjustment, all probe
program parameters can be set and modified at any time.
Specification
| Product | : 33 Zones LED Screen |
| Vertical Dimension | : 2230 x 850 x 700mm |
| Vertical Channel Dimension | : 2050 x 700mm |
| Net weight | : 43KG |
| Gross weight | : 48KG |
| Operating Voltage | : AC110~240V 50/60Hz |
| Power Consumption | : 12W |
| Operating frequency range | : 1–100 Bands |
| Working Environmental Temperature | : -20°C ~ 70°C |
| Maximum Sensitivity | : >6g metal |
Product Description
Functional Configuration:
1. Display: 7-inch operation LCD screen, new debugging program
interface, operation is more convenient and easy to understand.
2. Stand-up dimensions: 2230mm (H) × 835mm (W) × 700mm (D)
3. Vertical channel size: 1990mm (H) × 760mm (W) × 600mm (D)
4. Machine weight: 70KG
5. Working voltage: AC90V~240V 50/60Hz
6. Power consumption: <10W (lowest power consumption)
7. Operating frequency range: 1-100 frequency bands
8. Sensitivity: 0~999 adjustable
9. Working environment temperature: -20°C ~ 70°C
10. Accuracy range: Maximum sensitivity <2g metal (one paper clip size)
ADVANCED FEATURES
Multi-zone Technology: 33 zone detection, which identifies metal more accurately. Promise zone more accurately and quickly identify metal, while tracking metal moving position sound and light alarm.
Large screen Technology: 7-inch LCD screen, new debugger interface, easy to understand.
Detection of objects: Magnetic, non-magnetic and alloy metals can be detected.
Super-strong shell protection technology: IP55 superior protection performance.
We Provide Multiple Solutions
Can integrate a variety of access control equipments
Interactive Images
Easy Installing, NO Need Any Special Electrician Skills Fix on ground, connect to power supply, it will work
Product Details and Dimensions
All the details and dimensions can be customized according to your project site
